Supermicro and SupremeRAID™ Data Protection Solution

Empowering Performance and Reliability with Supermicro and SupremeRAID™

Solution Overview

SupremeRAID™ is the ultimate NVMe and NVMeoF RAID software designed to harness the processing power of GPUs. Award-winning SupremeRAID™ GPU-accelerated software RAID is designed to deliver unparalleled performance capabilities for demanding workloads across Linux and Windows systems, and supports PCI Express Gen 3, 4, and 5 technologies. SupremeRAID™ is unique RAID software running on a GPU card for the purpose of maximizing storage performance without consuming CPU cycles. With a single SupremeRAID™ card, users can achieve extraordinary results, boasting up to 28M IOPS and 260GB/s. Supporting up to 32 native NVMe drives, it empowers exceptional NVMe/NVMeoF performance while enhancing scalability, server lifespan, and cost-effectiveness.

Graid Solution diagram
Graid Solution

Solution Benefits

Supermicro and Graid Technology Inc. have partnered to offer a groundbreaking storage solution that pushes the boundaries of performance and reliability. By combining the cutting-edge technologies of both companies, users can enjoy several key benefits:

Unmatched Speed and Scalability

Harness the power of NVMe and advanced RAID technology for lightning-fast data access and unmatched scalability. Experience accelerated transfer rates, reduced latency, and seamless scalability for data-intensive workloads.

Enhanced Data Protection

Benefit from comprehensive data redundancy, fault tolerance, and RAID configurations.

Optimal Resource Utilization

This joint solution optimizes resource allocation by offloading CPU-intensive RAID operations to the GPU, enabling the CPU to focus on essential tasks. This efficient utilization of computing resources enhances multitasking capabilities, allowing for a more productive and responsive system.

Future-Proof Investment

With Supermicro and SupremeRAID™ by Graid Technology, you're investing in technologies designed for the future. Both companies are committed to innovation and continuously evolving their solutions to meet emerging storage requirements. Stay ahead of the curve and future-proof your storage infrastructure with this powerful joint solution.

Improved Reliability & Sustainability

Enhance server performance and lifespan with a battery-free solution, eliminating the risks of RAID battery-related degradation.

Solution Workflow

Unlike CPU-based software RAID and ASIC-based hardware RAID, which bottlenecks storage performance and reduces the return on investment (ROI) for NVMe SSD spend, SupremeRAID™ employs unique out-of-path technology, with data transfers occurring directly between the NVMe SSDs and the host memory. This direct connection allows data to be transferred at the full PCIe bandwidth of every NVMe SSD, delivering maximum storage performance, comprehensive data protection, unmatched configuration flexibility, attractive cost justification, and compelling value.

Graid Solution Workflow
Graid Solution Workflow

Unmatched Performance for NVMe Users

Graid Technology recently unveiled SupremeRAID™ software version 1.5, which delivers unmatched performance for NVMe users. This new software release harnesses the power of PCIe Gen 5technology, enabling users to achieve maximum performance while ensuring data integrity and security.

Benchmark Environment:

Hardware Spec:Server: Supermicro AS-2125HS-TNR
CPU: AMD EPYC 9654 96-Core Processor x 2
Memory: Samsung M321R2GA3BB6-CQKVS DDR5 16GB x 24
SSD: Kioxia CM7 KCMY1RUG3T84 x 24
RAID Controller: SR-1010 x 1
Software Environment:OS: Ubuntu 20.04.4 LTS
Kernel: 5.4.0-155-generic
Benchmarking tool: fio-3.16
SupremeRAID Driver version: 1.5.0

Performance results with SupremeRAID™ software version 1.5 on SupremeRAID™ SR-1010

SupremeRAID SR-1010 Performance
SupremeRAID SR-1010 Performance

Performance results with SupremeRAID™ software version 1.5 on SupremeRAID™ SR-1000

SupremeRAID SR-1000 Performance
SupremeRAID SR-1000 Performance

Industries and Use Cases

AI Training

Automobile, Aviation & Drone

Healthcare & Biotechnology

4K Video Surveillance

High Performance Computing

Research

Databases

SAN/NAS Storage Systems

Microscopy Instruments

including Light, Electron, & Cryogenic Electron

Certified Servers for SupremeRAID™ SR-1010

AS -2015CS-TNR

AS -2015CS-TNR

2UX12 12x 3.5/2.5"

CloudDC Server

AS -2015CS-TNR

  • Single 4th Generation AMD EPYC™ 9004 Series Processors
  • 12 DIMM slots up to 3TB 3DS ECC RDIMM DDR5-4800MHz
  • 2 PCIe 5.0 x16 FHFL, 2 PCIe 5.0 x16 FHHL
  • Dual AIOM with NCSI (OCP 3.0) for networking, 1 dedicated IPMI LAN
  • 12x 3.5/2.5" hot-swap hybrid NVMe/SATA/SAS drive bays
  • 1200W redundant Titanium level 100-240Vac and 200-240 Vdc power supplies(*Full redundancy based on configuration and application load)
AS -2125HS-TNR

AS -2125HS-TNR

2UX24 24x2.5’’

Hyper A+ Server

AS -2125HS-TNR

  • 4th Generation AMD EPYC™ 9004 Series Processors
  • 24x DIMM slots, DDR5-4800MHz memory, support up to 6 TB
  • 1 AIOM/OCP NIC 3.0 Slot
    For 24 SATA/SAS Configuration Options for up to 4 PCIe 5.0 x16 Slots or 8 PCIe 5.0 x8 Slots or 3 PCIe 5.0 x16 Slots + 2 PCIe 5.0 x8 Slots or 2 PCIe 5.0 x16 Slots + 4 PCIe 5.0 x8 Slots or 1 PCIe 5.0 x16 Slots + 6 PCIe 5.0 x8 Slots; For 24 NVME Configuration Options for up to 24 PCIe 5.0 x16 Slots OR 2 PCIe 5.0 x8 Slots
  • 24 hot-swap 2.5” NVMe/SAS/SATA
  • 1600W Redundant Power Supplies (Titanium Level)
SSG-221E-NE324R

SSG-221E-NE324R

2UX24 24xE3.S

Storage SuperServer

SSG-221E-NE324R

  • Dual Socket E (LGA-4677) 5th/4th Generation Intel® Xeon® Scalable processors. Up to 350W TDP.
  • Supports 32 DIMMs with 2DPC, up to 8TB memory capacity with 32 DIMMs of 256GB 3DS RDIMM DDR5-5600 ECC memory
  • Two PCIe 5.0 x16 slots & two PCIe x8 slots and two AIOM connectors (OCP 3.0 SFF compliant)
  • 24x hot-swap E3.S (7.5mm) NVMe drive bays
  • Redundant Titanium 2000W Power Supplies
SYS-221H-TN24R

SYS-221H-TN24R

2UX24 24x2.5’’

Hyper SuperServer

SYS-221H-TN24R

  • Dual Socket E (LGA-4677) 4th Gen Intel® Xeon® Scalable processors
  • 32 DIMM slots supporting up to 8TB of memory; RDIMMs up to DDR5-4800
  • Optional PCIe slot configurations up to 8 PCIe 5.0 x8 or 4 PCIe 5.0 x16 slots with support for double-width GPU/Accelerator cards
  • Flexible networking options with up to 2 AIOM networking slots (OCP NIC 3.0 compatible)
  • 24x 2.5" hot-swap NVMe/SATA/SAS drive bays; 2x internal M.2 NVMe/SATA drive slots
  • 4 heavy duty hot-swap fans with optimal fan speed control
SYS-620C-TN12R

SYS-620C-TN12R

2U X12 12x 3.5"

CloudDC SuperServer

SYS-620C-TN12R

  • Dual sockets P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
  • Intel® C621A Chipset
  • 16 DIMMs up to 6TB 3DS ECC DDR4-3200: LRDIMM/RDIMM/Intel® DCPMM
  • 4 PCIe 4.0 x8 FHHL (optional: combine into 2 PCIe 4.0 x16); 2 PCIe 4.0 x16 FHHL; 2 PCIe 3.0 x2 NVMe M.2
  • Dual AIOM (OCP 3.0) slots with NCSI for networking, 1 dedicated IPMI LAN
  • 12x 3.5/2.5" hot-swap hybrid NVMe/SATA/SAS drive bays
  • 3 heavy duty fans with optimal fan speed control, 1 air shroud
  • 1200W redundant Titanium level 100-240Vac and 200-240 Vdc power supplies
ASG -2115S-NE332R

ASG -2115S-NE332R

2UX32 32xE3.S

Storage A+ Server

ASG -2115S-NE332R

  • Single Socket SP5 AMD EPYC™ 9004 Series processors. Up to 350W TDP
  • Supports 24 DIMMs with 2DPC, up to 6TB memory capacity with 24 DIMMs of 256GB 3DS RDIMM/RDIMM DDR5 ECC memory
  • Two PCIe 5.0 x16 slots & two AIOM connectors (OCP 3.0 SFF compliant)
  • 32x hot-swap E3.S (7.5mm) NVMe drive bays
  • Redundant Titanium 2000W Power Supplies

Certified SupremeRAID™ Card

GPU-NVQT1000

GPU-NVQT1000

GPU-NVQRTX-A2000

GPU-NVQRTX-A2000
