Part Number |
Qty |
Description |
|
DVD-RW Drive
|
DVM-LITE-DVDRW24-HBT1 |
- |
BLACK LITE-ON 5.25" HH 24X DVD-RW SATA DRIVE (adding a DVD drive will limit the total number of SATA drives to 7) |
|
Gen3 8-ports SAS Raid controller kit
|
1x AOC-S3108L-H8IR-16DD and 2x CBL-SAST-0593 • |
- |
Enables the 8x hot-swap drive bays to support SAS drives |
|
Gen4 8-ports SAS Raid controller kit
|
1x AOC-S3908L-H8IR-16DD-P and 1x CBL-SAST-1264-100 |
- |
Enables the 8x hot-swap drive bays to support SAS drives |
|
Management Software
|
SFT-DCMS-SINGLE • |
- |
Supermicro System Managment Software Suite - 1 per node |
|
Middle Fan
|
FAN-0182L4 • |
- |
9.4K RPM, Hot-swappable Middle Cooling Fan for supporting GPU, PMem or 128GB and larger memory sizes |
|
NVMe Cable
|
CBL-SAST-0816 |
- |
SLIMLINE x8 to 2x Oculink x4 (1 cable supports 2x 2.5" NVMe drives in hotswap drive bays, connects to JNVMe1 on motherboard) |
| CBL-SAST-1154-85 • |
- |
SLIMLINE x8 to 2x Oculink x4 (1 cable supports 2x 2.5" NVMe drives in hotswap drive bays, connects to JNVMe2 on motherboard) |
|
OOB License
|
SFT-OOB-LIC |
- |
License for out of band management |
|
Rail Kit for rackmount
|
CSE-PT26L-B • |
- |
4U Chassis Rail Kit (w/ 2pcs Black Chassis Ears) |
|
Rear Fan
|
FAN-0180L4 • |
- |
9.4K RPM, Hot-swappable Rear Exhaust Fan for supporting PMem |
|
SATA Cable
|
CBL-SAST-0624 • |
- |
70cm SATA Cable (1pc required for DVD Drive) |
|
SATA Power adapter
|
CBL-0082L • |
- |
Y SPLIT SATA POWER ADAPTER (1pc required for DVD Drive) |
|
SuperCap kit for AOC-S3108L-H8IR-16DD
|
1x BTR-TFM8G-LSICVM02 • and 1x BKT-BBU-BRACKET-05 |
- |
SuperCap and mounting bracket for SAS RAID controller AOC-S3108L-H8IR-16DD |
|
SuperCap kit for AOC-S3908L-H8IR-16DD-P
|
1x BTR-CVPM05 • and 1x BKT-BBU-BRACKET-05 |
- |
SuperCap and mounting bracket for SAS RAID controller AOC-S3908L-H8IR-16DD |
|
TPM security module
|
AOM-TPM-9670V |
- |
SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor |
