| PCIe |
-
1 PCIe 3.0 x16 (in x16 slot),
-
2 PCIe 3.0 x4 (in x8 slot)
|
| BIOS Type |
|
| BIOS Features |
-
UEFI 2.3.1
-
USB Keyboard support
-
Hardware BIOS Virus protection
-
SMBIOS 2.7.1
-
Plug and Play (PnP)
-
APM 1.2
-
DMI 2.3
-
PCI 2.3
-
ACPI 1.0 / 2.0 / 3.0 / 4.0
|
| Software |
-
SuperDoctor® 5, NMI, KVM with dedicated LAN, IPMI2.0, AMT, vPro, Watchdog
|
| System Management Software |
-
SuperDoctor 5, IPMIView for Linux/Windows
|
| Power Configurations |
-
Power-on mode for AC power recovery, ACPI Power Management
|
| Voltage |
-
VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chassis intrusion header, 6 -fan status, 1.2V (VDIMM), +5V standby, +5V, +3.3V, +12V, +1.8V
|
| LED |
-
UID/Remote UID
-
CPU / System Overheat LED
|
| Temperature |
-
Monitoring for CPU and chassis environment
-
CPU thermal trip support
-
Thermal Monitor 2 (TM2) support
-
PECI
-
I2C temperature sensing logic
|
| FAN |
-
6x 4-pin fan headers (up to 6 fans)
-
Thermal control tachometer fan connectors, System level control, PWM fan speed control, Fan speed control, 6 fans with tachometer status monitoring, Pulse Width Modulated (PWM) fan connectors, Overheat LED indication
|
| Other Features |
-
WOL, UID, System level control, RoHS, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, Intel Smart Response Technology
|
| Operating Temperature Range |
-
0°C - 60°C (32°F - 140°F)
|
| Non-Operating Temperature Range |
-
-20°C - 60°C (-4°F - 140°F)
|
| Operating Relative Humidity Range |
-
10% - 85% (non-condensing)
|
| Non Operating Relative Humidity Range |
-
10% - 95% (non-condensing)
|
|
