Key Features

1. Intel® Xeon® W-3400 series, W-2400 series, W-3500 series, W-2500 series processors, Up to 60 CPU cores and a thermal design power (TDP) of up to 385W.
2. Intel® W790
3. Up to 4TB(W-3400/ W-3500)/2TB(W-2400/ W-2500) 3DS ECC RDIMM, 1TB(W-3400)/512GB(W-2400) ECC RDIMM; DDR5-4800MT/s(1DPC)/ 4400MT/s(2DPC), in 16 DIMM slots
4. M.2 Interface:  4 PCIe 5.0 x4
   M.2 Form Factor:  2280/22110
   M.2 Key: M-Socket (w/o heat sink)
5. 2 U.2 PCIe 3.0 for NVMe 2.5" SSD drives (U.2-1, U.2-2)
6. Xeon® W-3400/ W-3500 Series Processors: 6 PCIe 5.0 x16 Slots, support up to 6 Single Width/4 Double Width/2 Triple Width GPU cards Xeon® W-2400/ W-2500 Series Processors:3 PCIe 5.0 x16 Slots, support up to 3 Single Width/3 Double Width/2 Triple Width GPU cards (slot 3/5/7)
7. 1GbE LAN port with Intel® Ethernet Controller I210-AT
   10GbE LAN with Marvell AQC113C
8. 8 SATA 3 (6Gb, RAID 0, 1, 5, 10)

9. IPMI Supported
10. Overclocking Supported (optional)
